Sparse Upcycling: Building Senter Ohm's 32B MoE from an 8B Base

TOWARDS SELF-IMPROVEMENT — a 2026-06-07 design post by Chris (via Omni VA)

Naming. This post is about the Stage 3 build of Senter Ohm, the ~32A8B flagship. The smaller siblings — OmniSenter 12B (small function calling + omnimodal fusion) and OmniStep (multimodal + music) — are dense-ish models and don't go through sparse upcycling. Read the-omni-family.md for the full taxonomy.

This is the headline technical post of the catalog. Sparse upcycling is the technique that turns an 8B dense model into a 32B MoE with 8B active per token — the "32A8B" target of Senter Ohm. The math, the script, the design choices, and the wild cards.

The problem

You have a trained 8B dense model (the Stage 1 Senter SFT). You want a bigger model — more capable, more knowledgeable, but still fast. Training from scratch is impossible (your 2× 3090 doesn't have the VRAM for full fine-tune of a 30B+ model). Sparse upcycling is the answer.

The technique

Reference: Komatsuzaki et al. 2022 "Sparse Upcycling: Training Mixture-of-Experts from Dense Checkpoints" (Google).

The idea: take a dense transformer block (attention + FFN), copy the FFN N times to create N parallel "experts," add a small router on top, and continue-train briefly to teach the router which expert to use for which input.

BEFORE (dense):
┌──────────────────────┐
│   Self-Attention     │  (50M params)
├──────────────────────┤
│        FFN           │  (150M params)
└──────────────────────┘

AFTER (sparse upcycle, N=4):
┌──────────────────────┐
│   Self-Attention     │  (50M, shared)
├──────────────────────┤
│   ROUTER (top-1)     │  (~few M)
├──────────────────────┤
│   Expert 0 (FFN)     │  (150M)
│   Expert 1 (FFN)     │  (150M)
│   Expert 2 (FFN)     │  (150M)
│   Expert 3 (FFN)     │  (150M)
└──────────────────────┘

Per layer: 50M + 4×150M = 650M (was 200M). Across 36 layers + 0.6B embeddings = 24B total (was 8B).

Active per token (top-1 routing): 50M + 1×150M = 200M per layer. Across 36 layers + 0.6B embeddings = ~7.8B ≈ 8B. Same as the original 8B dense model.

So the model has 3× more parameters (24B vs 8B) but the same active compute per token (8B). At inference, only ONE expert fires per layer, so the FLOPs are identical to the dense model — but the model has 3× more knowledge baked in across the 4 experts.

The math (the 32A8B sweet spot)

N experts	Total params	Active @ top-1	Active @ top-2	Disk @ 4-bit	Inference VRAM (1× 3090)
1 (dense)	8B	8B	8B	4GB	6GB
2	13B	8B	9.5B	7GB	10GB
4	24B (24A8B)	8B	13B	13GB	17GB
6	35B (32A8B)	8B	13B	18GB	22GB
8	46B (50A8B)	8B	13B	24GB	28GB
10	57B (57A8B)	8B	13B	30GB	34GB

The math: - Each new expert adds ~5.4B params (the FFN of an 8B model) - Active per token stays at 8B with top-1 (just pick one expert) - Adding more experts = more knowledge, same compute

The sweet spot for Senter Ohm: 5-6 experts = 30-35B total, 8B active. Fits 4-bit on a single 3090 for inference (18-22GB VRAM), training is tight on 2× 3090 (~50GB peak with QLoRA).

The shared-expert design (DeepSeek-V2 style)

For N=6 with top-1, we have 6 experts, all routed. But there's a refinement from DeepSeek-V2: add 1 always-on shared expert + N-1 routed experts. The shared expert is small (e.g., 50% of a normal FFN) and always fires. The routed experts are top-1.

SHARED + ROUTED (N=4 routed, 1 shared):
┌──────────────────────┐
│   Self-Attention     │  (50M)
├──────────────────────┤
│   SHARED EXPERT      │  (75M, always on)
├──────────────────────┤
│   ROUTER (top-1)     │  (few M)
├──────────────────────┤
│   Routed 0 (FFN)     │  (150M)
│   Routed 1 (FFN)     │  (150M)
│   Routed 2 (FFN)     │  (150M)
│   Routed 3 (FFN)     │  (150M)
└──────────────────────┘

Per layer active (top-1): 50M + 75M shared + 150M routed = 275M. Across 36 layers: 9.9B + 0.6B = ~10.5B active.

Hmm — that's bigger than 8B. The shared expert adds to the active count. So the shared-expert design is best when you can afford ~10-11B active (the sweet spot of capability vs compute).

For the strict 8B active target, the design is no shared expert + top-1 routing (N=4-6 plain). For ~10-11B active (still fast, more capable per token), use shared expert + top-1 (N=3-4 routed).

The expert sources (what to distill into the experts)

The genius of sparse upcycling is that you don't have to train the experts from scratch — you can initialize them from existing specialist models and let the continued training specialize them.

Expert	Source	Why
Agentic expert	Stage 2 evolutionary merge	Best for tool use, multi-turn
Image/video expert	Distilled from Qwen3-Omni-30B-A3B (in your cache!)	Image + video understanding
Audio expert	Distilled from Qwen3-Omni's Whisper/FastConformer	Audio understanding
Music expert	Distilled from HeartMuLa or ACE-Step	Music understanding + description
Long-context expert	The YaRN-extended Stage 4 anchor	Retrieval at 100K+ tokens
Generalist fallback	Copy of base (diversifies via continued training)	Catch-all for unmatched inputs
Synesthesia expert	Distilled from ImageBind or trained on cross-modal data	The Synthesia cross-modal memory

The distillation extracts the FFN weights from the source model and uses them as one of the experts. The continued training then specializes each expert (1-5% of Stage 1's training budget = ~1 hour).

The script (sparse_upcycle.py)

Live at: multimodal-expansion/scripts/sparse_upcycle.py

# The headline command — 8B dense → Senter Ohm 32A8B
python3 sparse_upcycle.py \
    --base-model training-output/senter-ohm-8b-sft-20260606_213858/ \
    --expert-sources \
        models/qwen3-omni-30b-a3b/ \
        models/heartmula/ \
        models/long-context-anchor/ \
        models/synesthesia-expert/ \
    --output training-output/senter-ohm-moe-32a8b/ \
    --num-experts 6 \
    --top-k 1 \
    --shared-expert  # optional, for the 10.5B-active variant

The script: 1. Loads the base dense model 2. Finds all FFN blocks (mlp.gate_proj, mlp.up_proj, mlp.down_proj per layer) 3. Creates a MoE FFN with N experts + router 4. Initializes Expert 0 from the base FFN (always) 5. Initializes remaining experts from the --expert-sources (if provided) — extracts the matching FFN 6. Initializes the router to uniform + small noise 7. Saves the upcycled model with upcycle_metadata.json

The output is a standard safetensors model. Load it with transformers.AutoModelForCausalLM.from_pretrained() (with a small monkey-patch for the MoE FFN, or use a custom architecture class).

The continued training (teaching the router)

The upcycled model needs a SHORT continued training to teach the router. 1-5% of Stage 1's budget:

• Stage 1 was 4268 steps at ~5s/step (with the speed fixes) = ~6 hours
• Continued training: 100-200 steps at 5s/step = ~10-20 minutes

The training data should be a mix: - 50% agentic data (the original Stage 1 SFT data) - 20% multimodal examples (text descriptions of images/audio, Q&A) - 20% specialist data (whatever the experts were distilled from) - 10% retrieval examples (long-context, notebook-style)

The router is trained from scratch (initialized uniform + small noise). The other FFN weights are frozen at their source values — we only update the router. This is the magic: the upcycled model converges in 100-200 steps because the experts are already good, only the routing needs learning.

The wild cards

1. Expert collapse — the router might learn to always pick Expert 0 (the base). The fix: add a load-balancing auxiliary loss that penalizes uneven expert usage. The script has this.

2. Catastrophic forgetting — when you continue-train the router, the expert weights drift. The fix: keep them frozen. Only the router updates.

3. Router instability — early in training, the router weights can oscillate wildly. The fix: router jitter noise (small random noise added to router inputs during training). The script has this.

4. Expert quality variance — if one source model is much better than another, the routing will favor it and the others become dead weight. The fix: use a held-out validation set to monitor per-expert usage. If Expert X is < 5% of tokens, consider dropping it or reinitializing it from a different source.

5. The shared-expert trade-off — adding a shared expert increases the active count. For the 8B-active target, skip it. For the 10.5B-active target, include it.

6. GGUF conversion — llama.cpp doesn't natively support MoE architectures with custom routers. The fix: write a custom GGUF conversion that flattens the MoE to a multi-expert format. (This is on the roadmap, not done yet.)

What this enables

A Senter Ohm 32A8B MoE that: - Fits 4-bit on a single 3090 for inference - Trains QLoRA on 2× 3090 (tight, but doable) - Has 4× the knowledge of the dense 8B - Is fast at inference (8B active = same speed as the dense 8B) - Hosts Synthesia and Ohm as routed experts

Plus the headline: the Ohm runtime can evolve each expert separately, with the 14-dim Darwin genome applied to the entire MoE.

See also

• omnisenter-architecture — the system overview
• the-5-stage-pipeline — sparse upcycle is Stage 3
• senter-ohm-32a8b-math — the full sizing breakdown
• synthesia — the synesthesia expert that's one of the routed experts
• omnisenter-ohm — the self-evolving runtime that runs on top
• Script: multimodal-expansion/scripts/sparse_upcycle.py
• Reference: Komatsuzaki et al. 2022 "Sparse Upcycling"
